wasteboard hole pattern 1000mm x 1000mm
Project by
MICHAEL ILLINGBY
General Information
Want do make your own waste board? Want to manually drill all 144 holes perfectly? me neither. let your xcarve do it for you. Delete the ones that you dont need if your machine is smaller than mine. :)
Open in Easel®
Is spacing on the holes the same as the waste board from Inventables? TIA
Thomas Dukes
That was the whole point of the project you bet.
MICHAEL ILLINGBY
Thanks!!! I was wanting to make one to go on top of the original and use the existing threaded inserts to tie it down! AWESOME!!
Thomas Dukes
Does this include the holes to attach the board to the frame?
James Gibbons
In my particular situation, it did not line up to original holes. I have the 1000 x 1000. What would dead center coordinates be? Hoping that was my error..
Rick Rosales
Thomas, yes it is meant to lay overtop of the original so you can use the original threaded inserts.
MICHAEL ILLINGBY
Rick, I designed it to be zeroed at 0x0 so that it could be resized to any unit. Just centre you bit over the 0x0 and it should work fine like it did for me.
MICHAEL ILLINGBY
I'm about to try this but have a few questions. the holes say .625. my news wasteboard is .5 sgould i change the depth? Also my new wasteboard is 37x39.25. If i set my position to 0 and 0, is it going to carve in the right area?
robert robinson
Now I just need to figure out what OXO is LOL : )
Rick Rosales
Had the same issue. holes didnt line up. have no idea where to set zero now. Any suggestions?
Noel Fragoso
Rick im wondering what it means also . Mike what does OXO mean to us newbies
Cris rushing
0x0 is the zero point in x and y 0X x 0Y
MICHAEL ILLINGBY
